Ply-69L Linerless High Voltage Insulating Tape
A 30 mil (0,76mm) EPR, self-bonding, high voltage tape for
insulating and jacketing splices through 69 kv. Ply-69L is
linerless, and permits quicker application than a tape with liner.
Yields a void-free build-up. Excellent corona, ozone, and chemical
resistance. Ply-69L can also be used for building stress-cones on
power cable through 35 kv. ASTM-D-4388, HH-I-553C.A 30 mil (0,76mm)
EPR, self-bonding, high voltage tape for insulating and jacketing
splices through 69 kv. Ply-69L is linerless, and permits quicker
application than a tape with liner. Yieldsa void-free build-up.
Excellent corona, ozone, and chemical resistance. Ply-69L can also
be usedfor building stress-cones on power cable through 35 kv.
ASTM-D-4388, HH-I-553C.
Clicking on an item's Part Number will add it to your enquiry cart| CJS Catalogue Number | Colour | Dimensions |
|---|
| PLY-69L | Black | 19mm x 0,76mm x 9m |
Ply-69W Linered High Voltage Insulating Tape
A 30 mil (0,76mm) EPR, self-amalgamating, high voltage tape for
insulating and jacketing splices through 69 kv. Ply-69W amalgamates
quickly, yielding a void-free, electrically stable build-up and is
ideal for water-proofing. ASTM-D-4388, HH-I-553C / Grade A,
MIL-I-3825B.
Clicking on an item's Part Number will add it to your enquiry cart
Ply-Presafety-88 Pressure Sensitive
Glass Cloth Tape
A 7 mil (0,18mm) woven glass fabric tape with a
thermosetting rubber-based, pressure sensitive adhesive used for
insulating and protecting high temperature (130°C) connections,
such as motor leads and transformer windings.
Ply-Presafety 88 has high tensile
strength for splice reinforcement and provides excellent tear and
abrasion resistance. Use Ply- Presafety
88 to hold down 53 Ply arc- and fireproofing tape -
Communication Industry Specification 7611, ASTM-D-2754,
MIL-I-15126F/GFT.
Clicking on an item's Part Number will add it to your enquiry cart
Ply-Presafety-77 Grey Sealing Collar
Tape
Ply-Presafety 77 Sealing collar
tape has superior adhesive qualities and dielectric strength needed
to seal and insulate electrical connections. It is impervious to
ozone, water, soil, chemical or other corrosive chemical, UV
resistant. It is unexcelled for cold weather applications and
maintains flexibility and a tight seal even when subjected to
extreme flexure and has excellent thermal stability under load
cycling.
Clicking on an item's Part Number will add it to your enquiry cart
Ply-125 Rubber Filler Tape
Ply-125 electrical filler tape is a butyl rubber based
insulating compound in 1/8" thick tape form designed for quick,
cost effective insulation build-ups. Ply-125 is a self-amalgamating
compound that can be readily compressed and
molded by hand to conform to irregular shapes
and contours and can be used as primary insulation for splices
through 5kV in conjunction with other insulating tapes, Ideal for
covering split bolts, padding bus bar edges and connections and
provides excellent moisture seal. Model: MIL-I-17695A.
Clicking on an item's Part Number will add it to your enquiry cart| CJS Catalogue Number | Colour | Dimensions |
|---|
| PLY-125 | black | 38 mm x 3.2 mm x 1.5 m |
Ply-Presafety 83 Cable Prep Kit
Ply-Presafety 83 is
an effective and environmentally friendly cleaning kit for the
proper preparation of both high and low voltage cables prior to
splicing or terminating. It is very effective for removing grease,
oil, tar, and other contaminants from cables. Kits have everything
necessary to prepare cables for a splice or termination. Each kit
contains one set of cleaning wipes and one piece of 120-grit
non-conducting abrasive cloth.
